ydoc umlautogen image broken

+1 vote

hello,



i tried uml doclet and its uml image generator, but i got broken images. Why? Can someone  help me? thank you

closed with the note: This forum is for yEd questions only! Please contact yDoc support for yDoc questions.
asked Sep 30, 2012 in Feature Requests by svatos.jirka (130 points)
closed Oct 1, 2012 by thomas.behr
I too am seeing this. I am using this in Maven like so (the version is 3.0_02-jdk1.5):

            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-javadoc-plugin</artifactId>
                <version>2.9.1</version>
                <configuration>
                    <!-- Doclet -->
                    <doclet>ydoc.doclets.YStandard</doclet>
                    <docletPath>${yworks.uml.path}/lib/ydoc.jar:${yworks.uml.path}/lib/class2svg.jar:${yworks.uml.path}/resources</docletPath>
                    <additionalparam>-umlautogen</additionalparam>
                    <!-- bootclasspath required by Sun's JVM -->
                    <bootclasspath>${sun.boot.class.path}</bootclasspath>
                    <!-- General Javadoc settings -->
                    <doctitle>${project.name} (${project.version})</doctitle>
                    <show>private</show>
                    <docfilessubdirs>true</docfilessubdirs>
                    <additionalJOption>-J-Xmx1024m</additionalJOption>
                    <verbose>true</verbose>
                </configuration>
            </plugin>

and other than the broken images it seems to work pretty well.
This forum is for yEd questions only! Please contact yDoc support for yDoc questions.
